| MODEL | IDA245 |
|---|
| Read Range | 3m(10feet) with RF245-3, 5m(17feet) with RF245-5, 10m(34feet) with RF245-10 |
| Frequency | 2.45GHz |
| Directivity | Omni - directional |
| Antenna | Monopole Antenna |
| Transmit Power | IDA245: -20dBm / IDA245H2 : -10dBm |
| Modulation | Encrypted GFSK |
| Wake-up Time | Approx. 0.7sec |
| Site Code | 256Site Code (000~255) |
| Tag ID numbers | Maximum 16 Millions ID Numbers per Site Code |
| Encryption | 16bit IDTECK’s Secured Algorithm |
| Power | Coin Cell Lithium Battery, 3V 150mAh, CR2025 |
| Battery Life Time | Life-time |
| Operating Temperature | -20°C to +65°C (-4°F to +149°F) |
| Operating Humidity | 10% to 90% relative humidity non-condensing |
| Dimension (W x H x T) | 2.1” x 3.4” x 0.18” (54mm x 86mm x 4.5mm) |
| Weight | 20g (0.04lbs) |
| Warranty | 1 Year |
|
|
| Transparency |
| White (Front), Beige(Rear) |
|
|
|
| 11.5g (0.03lbs) |
| 20g (0.04lbs) |
|
|
|
|
